1x New SONY AC-148F PHANTOM 2 Channel AC Power Supply for Microphones

Listing details

Type
Microphone Power Supply
Brand
Sony
Model
AC-148F
Condition
New (Open Box)
?
The item is in excellent, new condition with no functional defects. The item may be missing original packaging and may have been used for testing or demo purposes. The item includes all the accessories found with the original product.

Product details

New Sony AC-148F phantom 2 channel AC power supply for microphones.
Phantom power is supplied to two microphones that require external power supply, such as condenser microphones C-48 and C-38B, and lavalier microphone ECM series.
Main specifications:
● Method: 2-channel external power supply method
● Open end output power supply: DC49V ± 1V
● Maximum supply current: approx.
14mA (1ch *) ● Internal resistance: 3.5kÎĐ Âą 10%
● Ripple voltage: 50ξV or less (RMS)
● Connector:
AC-148F microphone side ... Canon XLR-3-31 equivalent (x2)
AC-148F output side ... Canon XLR-3-32 equivalent (x2)
● Power supply voltage: AC100V, 50 / 60Hz
● Power consumption: 4W (Maximum)
● Ambient operating temperature: -20- + 60 ℃
● External dimensions (width x height x depth): approx. 201 x 74 x 169mm
● Weight: approx. 2 kg (main unit)
We are open to any questions!
One item in one lot.
We ship via Expedited Shippimg.
Tracking number is provided.
